TE Connectivity Schrack RT424024 Relay 24V DC 8A DPDT
- Schirmer item number
- 2243
- Manufacturer
- TE Connectivity
Available
21.42 €*
18.00 € net, plus 19 % VAT (delivery to Germany)
* All prices incl. statutory VAT, plus shipping costs
6.19 €
Estimate for this item and the selected quantity. Final totals and any tax adjustments are calculated at checkout.
We dispatch items in stock within 1–2 working days of receiving payment, or after order confirmation for purchases on invoice. Delivery after dispatch: Germany 1–3 working days, other EU countries 3–7 working days, Switzerland, Norway, Iceland and Liechtenstein 5–10 working days.
Non-binding. We will confirm price and availability.
Secure payment methods
Insured shipping
All items are shipped insured, including DHL tracking. Express shipping is available on request.
Questions about this product?
Please compare the model and version with your part. Unsure about compatibility or what is included? Ask us about this item.
Product details & specifications
High-performance PCB relay from the Schrack RT2 series with 24V DC coil and 2 changeover contacts (DPDT).
General
| Manufacturer | TE Connectivity |
|---|---|
| Type / Model | TE Connectivity Schrack RT424024 Relay 24V DC 8A DPDT |
| Item number | 2243 |
| Contact configuration | 2 changeover contacts (DPDT / 2 Form C) |
| Coil voltage | 24V DC |
| Rated current | 8A |
| Mounting type | PCB-THT |
Technical data
| Maximum switching voltage | 400VAC |
|---|---|
| Contact material | AgNi 90/10 |
| Coil power | 400mW |
| Operating temperature | -40 to 85°C |
| Electrical insulation contact-coil | 5000Vrms |
| Clearance/creepage distance contact-coil | ≥10/10mm |
| Dimensions | 29 × 15.7 × 12.7 mm |
| Protection type | RTII flux proof |
